BIM Revit 2023 Mech (Project Workflow from Start to End)

The BIM Revit Mechanical (Project Workflow) course teaches you how to design and implement mechanical systems (HVAC, drainage, water supply) using Revit MEP within a professional BIM environment.

You’ll learn step-by-step through a practical project how to create models, coordinate with other disciplines, and produce final drawings and documentation.

Course Main Contents:

1. Introduction

2. Starting New Project

3. Mechanical Template

4. Mechanical Modelling

5. MEP Coordination

6. Mechanical Sheets Extraction

7. Schedules

8. Work-sharing

Notes:

1. The idea of the course is to learn the Revit from the contractor point of view, also to learn the Revit mechanical for design point of view, after the course you will have full technical support. (Essentials & Advanced)

2. You will learn how to start new project.

3. You will learn how link and coordinate with Arch & Structure

4. You will learn how to make coordination between mep Services.

5. You will learn how to extract sheets from Revit

6. You will learn how to extract schedules from Revit

7. the version of Revit is 2023 but the course is applicable for any version of Revit

8. you will learn how to make HVAC model, Plumbing model and FF model.

9. the course implemented on small scale project, but it is applicable for any size of projects, you will learn the steps general for the project.
